Product Introduction
1. Overview
The IQIEGE-155D is a specialized, basic metallographic sample-preparation instrument that employs a high-speed rotating thin-slice cutting wheel to section metallographic specimens. It is particularly well suited for cutting relatively hard metallic materials and is equipped with a dedicated cooling system that effectively dissipates heat during the cutting process, thereby preventing thermal-induced microstructural changes in the specimen. The machine features a compact design, simple operation, and highly targeted functionality. Its key highlights include a forced-cooling protection mechanism and a cutting design optimized for hard metals; it has a maximum cutting diameter of 55 mm and is operated entirely by manual lever control. Powered by a 2.2 kW motor running at 2,800 rpm, it can readily meet the demand for rapid sectioning of small metal specimens in routine laboratory settings, making it an economical and practical entry-level metallographic preparation solution for factories, research institutions, and university laboratories.
2. Main Technical Specifications
|
Maximum Cutting Cross-Section
|
55×55mm
|
|
Cutting Disc Specifications
|
Φ300×2×32mm
|
|
Spindle speed
|
2,800 rpm
|
|
Motor power
|
2.2KW
|
|
Input Power
|
Three-phase AC 380 V, 50 Hz
|
|
External dimensions
|
650×500×400mm
|
|
Net weight
|
80kg
|
