The ZXQ-2 automatic metallographic sample mounting machine is ideally suited for mounting tiny, difficult-to-handle, or irregular metallographic and petrographic specimens, facilitating subsequent cutting, grinding, and polishing before metallographic, spectroscopic, or hardness testing. During the sample preparation process, the machine is fully programmably controlled by a microcontroller, automating a sequence of operations—including automatic heating, pressurization, gradual cooling, and final automatic pressure relief and shutdown—thus enabling unattended operation throughout the entire procedure. This design underscores the machine’s user-friendly interface, simple operation, and exceptional efficiency.
Product Introduction
I. Overview:
The ZXQ-2 automatic metallographic sample mounting machine is ideally suited for mounting tiny, difficult-to-hold, or irregular metallographic and petrographic specimens, facilitating subsequent cutting, grinding, and polishing before metallographic, spectroscopic, or hardness testing. During the sample preparation process, the machine is fully programmably controlled by a microcontroller, automating a sequence of operations—including heating, applying pressure, automatic cooling, and finally automatic pressure relief and shutdown—thus enabling unattended operation throughout the entire procedure. This design underscores the machine’s user-friendly interface, simple operation, and exceptional efficiency.
II. Main Technical Parameters:
|
Specimen pressing diameter
|
Three specifications: φ22, φ30, and φ45 (one standard configuration; select when ordering).
|
|
Heating temperature range
|
100-200℃
|
|
Cooling temperature range
|
20-90°C
|
|
Holding pressure time range
|
0-999s
|
|
Heating power
|
450–1000 W
|
|
Input Power
|
Single-phase AC 220V 50Hz
|
|
External dimensions
|
350 mm × 450 mm × 470 mm
|
|
Net weight
|
45Kg
|
