คำอธิบาย
The GTQ-5000B precision cutting machine is designed for the precise, deformation-free cutting of a wide range of materials, including metals, electronic components, ceramic materials, crystals, cemented carbides, rock and mineral samples, concrete, organic materials, and biological materials such as teeth and bone. This equipment is driven by a high-power servo motor, offering exceptional positioning accuracy, an extensive speed-adjustment range, and robust cutting performance. It features a built-in recirculating cooling system, programmable feed-rate settings, menu-based control, and an LCD display. Users can freely define cutting parameters, and the machine is equipped with a sealed cutting chamber fitted with a safety interlock. It is one of the ideal instruments for industrial and mining enterprises as well as research institutes engaged in the preparation of high-quality test specimens.
Product Introduction
I. Overview
The GTQ-5000B high-speed precision cutting machine is designed for the precise, deformation-free cutting of a wide range of materials, including metals, electronic components, ceramic materials, crystals, cemented carbides, rock and mineral samples, concrete, organic materials, and biological materials such as teeth and bone. This equipment features PLC control for high positioning accuracy, a broad speed-adjustment range, powerful cutting performance, and an efficient recirculating cooling system. It offers presettable feed rates, a large touchscreen interface for intuitive operation and monitoring, and automated cutting to reduce operator fatigue while ensuring consistent sample preparation. The system also provides real-time monitoring and alarm alerts throughout the cutting process. Its spacious, well-lit cutting chamber equipped with safety interlocks makes it an ideal choice for industrial and mining enterprises as well as research institutes seeking to produce high-quality test specimens.
II. Detailed Specifications
|
|
GTQ-5000B High-Speed Precision Cutting Machine |
|
Feed rate |
0.01–3.00 mm/s (adjustment step: 0.01) |
|
Cutting saw blade speed |
500~5000 rpm |
|
Maximum travel distance |
Y-axis 200mm |
|
Cutting disc size |
200×1×32mm |
|
Lighting lamp |
Built-in |
|
Cutting power |
1000W |
|
Power Supply |
220V 50Hz |
|
External dimensions |
750 mm × 630 mm × 400 mm (length × width × height) |
