The IQIEGE 130D is a specialized, entry-level metallographic sample-preparation instrument that employs a high-speed rotary thin-slice cutting disc to section metallographic specimens. It is particularly well suited for cutting relatively hard metallic materials and is equipped with a dedicated cooling system that effectively dissipates heat during the cutting process, thereby preventing overheating and thermal damage to the specimen microstructure. The machine features a compact, space-saving design, simple operation, and highly targeted performance. Its key highlights include a forced-cooling protection mechanism and a cutting design optimized for hard metals, with a maximum cutting capacity of 30 mm and fully manual lever control. Powered by a 1.1 kW motor running at 2,800 rpm, it can readily meet the demand for rapid sectioning of small metal specimens in routine laboratory settings, making it an economical and practical entry-level metallographic preparation device for industrial facilities, research institutions, and university laboratories.
Product Introduction
1. Overview
The IQIEGE 130D is a specialized, entry-level metallographic sample-preparation instrument that employs a high-speed rotary thin-slice cutting wheel to section metallographic specimens. It is particularly well suited for cutting harder metallic materials and is equipped with a dedicated cooling system that effectively dissipates heat during the cutting process, thereby preventing overheating and thermal damage to the specimen microstructure. The machine features a compact, space-saving design, simple operation, and highly targeted performance. Its key highlights include a forced-cooling protection mechanism and a cutting design optimized for hard metals, with a maximum cutting capacity of 30 mm and fully manual lever control. Powered by a 1.1 kW motor running at 2,800 rpm, it can swiftly section small metal specimens in routine laboratory settings, making it an economical and practical entry-level metallographic preparation device for factories, research institutions, and university laboratories.
2. Main Technical Specifications
|
Maximum Cutting Cross-Section
|
30×30mm
|
|
Cutting Disc Specifications
|
Φ250×2×32mm
|
|
Spindle speed
|
2,800 rpm
|
|
Motor power
|
1.1KW
|
|
Input Power
|
Three-phase AC 380 V, 50 Hz
|
|
External dimensions
|
650mm × 450mm × 400mm
|
|
Net weight
|
60kg
|
