The XQ-2B metallographic specimen mounting machine is ideally suited for mounting small, difficult-to-handle, or irregular metallographic and petrographic specimens, facilitating subsequent cutting, grinding, and polishing prior to metallographic analysis, spectroscopic examination, or hardness testing. The machine is programmably controlled and offers three operating modes: standard bakelite powder, electroceramic powder, and a user-defined option. Notably, the sample preparation program precisely controls the mounting time—a domestic first—enabling unattended operation throughout the entire process. The XQ-2B metallographic specimen mounting machine is an ideal sample-preparation solution for laboratories at colleges and universities as well as industrial and mining enterprises.
Product Introduction
I. Overview:
The XQ-2B metallographic specimen mounting machine is ideally suited for mounting small, difficult-to-handle, or irregular metallographic and petrographic specimens, facilitating subsequent cutting, grinding, and polishing prior to metallographic analysis, spectroscopic examination, or hardness testing. The machine is programmably controlled and offers three operating modes: standard bakelite powder, electroceramic powder, and a user-defined option. Notably, the sample preparation program precisely controls the mounting time—a domestic first—enabling unattended operation during the mounting process. The XQ-2B metallographic specimen mounting machine is an ideal sample-preparation device for laboratories at colleges and universities as well as industrial and mining enterprises.
II. Main Technical Parameters:
|
Specimen pressing diameter
|
Three specifications: φ22, φ30, and φ45 (one standard configuration; select when ordering).
|
|
Temperature control range
|
Room temperature to -200°C
|
|
Timing Range
|
0-890S
|
|
Total machine power
|
≤800 W
|
|
Input Power
|
Single-phase AC 220 V, 50 Hz
|
|
External dimensions
|
440 mm × 253 mm × 310 mm
|
|
Net weight
|
32Kg
|
