INSIZE ISF-S200 Digital Spring Tester (200N; 0.05N)
- Peak hold and automatic release function
- Set upper and lower limits, Red and green indicator and buzzer alarm
- Automatic conversion of three units: N, Kgf, Ibf
- Built in printer
- Automatic power off
Specification
Maximum load: 200N
Resolution: 0.05N
Range of digital scale: 95mm
Resolution of digital scale: 0.01mm
Disk diameter: Ø49mm
Maximum free length of spring: 95mm
Measuring range of force: 5%~100% (maximum load)
Accuracy of force: ±1% (maximum load)
Data output: RS232
Power supply: 220V, 50/60Hz
Dimension: 300x235x620mm
Weight: 19.1kg
อุปกรณ์หลัก
Main unit : 1 pc
Power supply adapter: 1 pc
